Telefunken TDP-2 Stereo Passive DI

Telefunken South Africa

The Telefunken TDP-2 Stereo Passive DI combine premium though-hole components, European-made transformers and rugged, road-ready construction to deliver rich, warm tone in any environment.






SKU: SYTM-083 Category: Tags: , , Brand:

Telefunken TDP-2 Stereo Passive D

The Telefunken TDP-2 Stereo Passive DI combine premium though-hole components, European-made transformers and rugged, road-ready construction to deliver rich, warm tone in any environment. Boasting an ultra-flat frequency response with extremely low distortion and self-noise, the TDP direct boxes excel at capturing everything from synthesizers and keyboards to acoustic-electric guitar and electric bass with a certain subtle and unique character.

Telefunken TDP-2

At the heart of all TELEFUNKEN Elektroakustik direct boxes are custom-wound output transformers made in England by OEP/Carnhill. Each channel features premium metal Amphenol connectors and recessed metal switches to engage the -15 dB pad and ground lift. These elements combined with premium passive components (including 1% tolerance metal film resistors, and WIMA and Nichicon capacitors) are all housed in a rugged aluminum chassis designed to withstand the wear and tear of the road. Like all TELEFUNKEN microphones, all TDP direct boxes are assembled and critically tested in Connecticut, USA. Check out the TDP-1!


Switched On: The Brand Reborn

The TELEFUNKEN Story!






  • Custom-wound OEP/Carnhill transformer, made in the UK
  • -15 dB pad switch
  • Ground lift switch
  • Rugged aluminum construction
  • Recessed switches and connectors for protection
  • 100% through-hole components
  • Amphenol connectors
  • WIMA and Nichicon capacitors
  • 1% 1/4W metal film resistors
  • 3-year warranty
  • Type: Passive Direct Box



  • Type: Passive Direct Box
  • Frequency Range: 10 Hz – 70 kHz, ±1 dB
  • Transformer: Custom-Wound OEP/Carnhill
  • Input Impedance: > 20 kΩ
  • Output Impedance: < 200 Ω
  • Maximum SPL (for 1% THD): > +18 dBV
  • Input Connections: 1/4″ Jack
  • Output Connections: XLR Output, 1/4″ Thru
  • Dimensions: 100 mm L x 100 mm W x 50 mm H
  • Weight: 490 g
  • Included Accessories: Cloth Drawstring Bag
